PZL-104M Wilga 2000 performance and specifications
PZL "Warszawa-Okęcie"
S.A. (Poland) main production lines are light
aircraft designed by its own R&D Division. They
range from general aviation, multipurpose A/cs,
through agricultural aircraft up to military
trainers. The Company specialises mainly in
manufacturing of complete airframes and installing
of engines, instruments and avionics purchased
from world-renown companies. The company is now
part of the EADS group.
A four seat
multipurpose aircraft of STOL class which may be
widely used as:
- An executive
A/c
- Air club
general use, parachuting, glider and banner
towing and training A/c
- Air ambulance
- Patrol A/c
- Agricultural
A/c
It may be equipped
with:
- FLIR
- Pollution
detectors
- Retransmission
equipment and small arms.
"Wilga" 2000 may
be supplied with wheels, skies and/or floats. It
conforms with FAR 23.
TECHNICAL DATA
Dimensions:
Span -
11,28 m
Length - 8,46 m
Wing area - 15,5 m2
Doors
dimensions - 1,63 x 0,95 m |
|
Weights:
Take-off
weight - 1400 kg
Empty weight - 1000 kg |
Performance:
Stalling
speed - 89 km/h
Rate of climb - 4,9 m/s
Max. range - 1400 km at cruise speed 175
km/h
Take-off / Landing run - 272/165 m
Max. VH
- 195 km/h |
|
|
