WACO YKS-6 / YKS-7 performance and specifications




A series of four to five seat cabin biplanes were produced from 1935. These were a little larger than earlier Waco types, and more luxurious. They generally had short span lower wings and quite elegant lines, and sold well despite higher prices. The YQC-6 was offered with a choice of no less than seven different engines, the Jacobs L-6 being the largest.

A number were exported to Canada and India, and some were fitted with freight doors.

A custom cabin version was also available. information kindly supplied by Lars & Angelika Opland


The older ones, circa 1935 (YOC, CUC, etc.), were shorter than later ones by 1 foot. The strong recurve in the fuselage profile aft is the main recognition feature


From 1936 on (EQC-6, ZQC-6, etc.), the fuselage is 1 foot longer with straighter lines in the aft profile. Rear windows were not always present, so are not recognition features

The wings are a major recognition feature between standard cabins & custom cabins. In the standard cabin series you have true biplanes with bottom wings that are the same cord & not much shorter in span than the top wings. Custom cabins have bottom wings that are markedly smaller in both span & cord.

standard cabin:

1937 Custom Cabin

WACO YQC-6

  • TYPE: 4-5 seat light transport
  • COUNTRY OF ORIGIN: United States
  • ENGINE: One Jacobs L-4M piston engine of 225 hp.
  • DIMENSIONS:
    • Span: 34 ft 7 in / 10.54 m.
    • Length: 26 ft 6 in / 8.08 m.
    • Height: 8 ft 7.5 in / 2.63 m.
  • PERFORMANCE:
    • Max. speed; 123 kts / 228 kph
    • Cruising speed: 100 kts / 185 km/hr
    • Service ceiling: 14,000 ft / 4,267 m.
  • WEIGHTS:
    • Empty: 2,076 lb / 938 kg
    • Loaded: 3,475 lb / 1576 kg
  • CAPACITY: 4-5
