Aerospatiale-Socata TB-9
Tampico Club
Missions
. Basic
Training
. Travels
. Liaisons
. VFR amd IFR Training
Overview
The 160-HP Socata TB9 Tampico GT is
the entry-level aircraft in the TB series, yet still
offers all standard GT features: new design, composite
canopy, flush-mounted windows, newly redesigned
wingtips and enlarged baggage door.
Few aircraft used in flying schools may be described
as "comfortable". But that's the word that comes up
most often when talking about the TB9 flying
classroom. The new TB9 offers high performance, thanks
to the GT-series aerodynamic improvements, along with
wheel fairings and a Sensenich propeller optimized for
cruise.
A new trailing-link type fixed landing gear enables
the Tampico GT to support high-cycle operation the
durability demanded by flight schools.
The Tampico GT's high wing loading yields excellent
response even in turbulence, and offers the solid ride
of heavier aircraft. The centre console is easy to
reach and controls are especially practical, making
the airplane a joy to fly.
Configuration
|
|
Single engine |
Low-wing monoplane with semi-monocoque metal
construction |
Certified to FAR 23, parts 1 to 16. |
Seats : 2 forward, bench for 2 aft. |
|
Power Plant
|
|
Manufacturer :
|
Lycoming
|
Type :
|
O-320-D2A 4 cylinders
|
Power rating :
|
160 BHP at 2,700 RPM
|
Recommended TBO :
|
2,000 hours
|
|
Propeller
|
|
Manufacturer :
|
Sensenich Twin Blade
|
Diameter :
|
74 in
|
1.88 m
|
|
Fuel
|
|
Fuel type :
|
100 LL
|
|
Total tank capacity :
|
41.7 US gal
|
158 l
|
Usable fuel capacity :
|
40.2 US gal
|
152 l
|
|
Oil
|
|
Total oil capacity :
|
8.45 US quarts
|
8 l
|
|
Weights
|
|
Average empty weight :
|
1,440 lbs
|
653 kg
|
Max. take off weight (MTOW) :
|
2,337 lbs
|
1,060 kg
|
Max. landing weight :
|
2,337 lbs
|
1,060 kg
|
Max. useful load :
|
897 lbs
|
407 kg
|
Max. luggage capacity in storage :
|
143 lbs
|
65 kg
|
Max. wing loading :
|
18.24 lbs/sq.ft
|
89.1 kg/m2
|
|
Performances
ISA conditions at max. take-off weight
|
|
Rate of climb (sea level - max weight):
|
665 ft/mn
|
|
Max. cruis. speed 6,000 ft at 70% W:
|
115 KTAS
|
|
Best eco.cruis.spd. 8,000 ft at 65% :
|
109 KTAS
|
|
Demonstrated crosswind :
|
25 kt
|
|
Operating ceiling :
|
11,000 ft
|
|
Take off over 50 ft obstacle :
|
1,866 ft
|
570 m
|
Landing over 50 ft obstacle :
|
1,378 ft
|
420 m
|
|
Dimensions
|
|
Wing span :
|
32.84 ft
|
10,04 m
|
Length :
|
25.33 ft
|
7.72 m
|
Height :
|
9.91 ft
|
3.02 m
|
Cabin length :
|
8.30 ft
|
2,53 m
|
Cabin width :
|
4.20 ft
|
1.28 m
|
Cabin height :
|
3.94 ft
|
1.20 m
|
Wheel track :
|
7.55 ft
|
2,30 m
|
Wing airfoil :
|
RA 16 3C3
|
|
Wing area :
|
128.1 sq ft (2)
|
11.9 m2
|
|
|
|
