General Avia F15F/F15E Picchio performance
and specifications


The F15F
four-seat light aircraft is a derivative of the
Procaer F15E Picchoi. First flight was in
October 19977 and a pre-production batch was under
construction during 1978. The F15E Picchio
is slightly shorter than the F15F and features a
conventional enclosed cabin compared with the new
aircraft's fully glazed sliding canopy. The
first F15 Picchoi flew in 1959 and successive
models built since then have featured a number of
detail design changes including the addition of
wingtip fuel tanks. Most important change
was the switch to all-metal construction with the
F15E, which first flew in 1968. Cruising
speed of the F15F is 174 mph (280km/hr).
F.15E Picchio
|
Powered by |
300 hp
Continental IO-520-F |
| Propeller |
Hartzell constant speed |
| Wing span |
32' 6" |
| Length |
24' 7" |
| Wing area |
143 sq ft |
| Gross weight |
3,000 lbs |
| Empty weight |
1,856 lbs |
| Accommodation |
4 seats |
| Maximum speed |
205 mph |
| Maximum cruise speed |
187 mph |
| Economy cruise speed |
166 mph |
| Stall speed |
67 mph |
| Maximum range |
920 sm |
|
