General Avia F-20 Pegaso performance
and specifications
History
In January 1970 Dott. Ing. Stelio Frati, renowned
as a freelance designer of a series of successful
light aircraft built by manufacturers such as
Ambrosini, Aviamilano, Caproni, Pasotti, Procaer
and SIAI Marchetti, established Construzioni
Aeronautiche General Avia to construct prototypes
of his designs. The first new type to be developed
at the Milan workshops was the F-20 Pegaso, a
six-seat twin-engined light executive transport
aircraft. Work on the first prototype commenced in
September 1970; it was first flown on 21 October
1971, and a second prototype, slightly larger and
heavier than the first, flew on 11 August 1972.
Contemporaneously with the establishment of General Avia, a
publisher Dr. Gianni Mazzocchi was setting up
Italair SpA to provide development, manufacturing
and marketing facilities for light single- and
twin-engined aircraft, and this organization took
over the two prototypes to conduct the
certification programme in anticipation of
production. Type approval was granted by the RAI
on 19 November 1974, and by the FAA on 14 May
1975. By agreement production was handed back to
General Avia and the first Aircraft flew on 17
December 1979, incorporating a number of minor
changes which included improved cabin heating and
sound-proofing and the substitution of three blade
Hartzell propellers for the original two blade
units.
A four seat military version is available as the F-20 Condor,
which can be fitted three stores pylons under each
wing the central carrier accepting a 50 Imp. gal.
fuel tank. Military roles include long range
maritime surveillance, search and rescue, and
weapons training. The specification applies to the
General Avia F-20 Pegaso.
Specifications
Powered by |
Two 300 hp
Continental IO-520-K |
Propeller |
Hartzell constant speed |
Wing span |
33' 11" |
Length |
26' 10-3/4" |
Wing area |
172.4 sq ft |
Gross weight |
5,070 lbs |
Empty weight |
3,086 lbs |
Accommodation |
5-6 seats |
Maximum speed |
242 mph |
Maximum cruise speed |
230 mph |
Economy cruise speed |
220 mph |
Stall speed |
72 mph |
Rate of climb |
2,000 fpm |
Service ceiling |
20,500 ft |
Maximum range |
1,110 sm |
|
|
