Coot Amphibian


The Coot is a homebuilt amphibian that features
high-lift wings which fold for trailering and which do not require
flaps. They emerge from the mid-hull for superior ground effect
during water take-off and landing. Because the wing roots (sponsons)
rest on the water there is no need for wing-tip floats. The low wing
also allows for a lower centre of thrust, and safe and manoeuvrable
handling during step-taxiing. There is no "kit," but contoured
fibreglass hull parts are available.
specifications
powerplant
propeller
length
height
wing span
wing area
seats
empty weight
useful load
gross weight
fuel capacity
range |
150-220 hp
x
22 ft
8 ft
36 ft
180 sq ft
2
1450 lb
x
1950 lb
28-40 gal
x |
performance
takeoff
distance, ground roll
rate of climb
max speed
cruise speed
landing distance, ground roll
service ceiling |
x
600-800 fpm
x
100-120 mph
x
x |
limiting and recommended speeds
design
manoeuvring speed (Va)
never exceed speed (Vne)
stall, power off (Vsl)
landing approach speed |
x
x
45-48 mph
x |
All specifications are based on
manufacturer's calculations |

|
|
