Corby Starlet
The Starlet was designed by
Australian aero engineer John Corby for a competition held by
English company Rollason Aircraft Ltd in 1964. The design was placed
eighth, although it became the first from the competition to be
built. The prototype (VH-CBS) first flew on August 9th, 1967. The
semi-aerobatic aircraft is of all wood construction, and features
plywood and fabric covering.
|
Model: |
Corby
Starlet CJ-1 |
|
Group Code: |
CONV |
|
Landing Gear: |
FG (Tailwheel) |
|
Seats: |
1 |
|
Construction
Material: |
Spruce & Plywood |
|
Engine: |
VW or Jabiru |
|
Horsepower: |
VW 45 - 75 hp
Jabiru 80 hp |
|
Propellor: |
Wood 54 inch |
|
Maximum Speed: |
139 kts @ sea level |
|
Cruise Speed: |
113 kts |
Stall (or Min.) Speed:
@ gross w/ full flaps |
30 kts |
|
Service Ceiling: |
14,500 ft (4419
m) |
|
Takeoff Distance: |
350 ft (106 m) |
|
Landing Distance: |
450 ft (137 m) |
|
Rate of Climb (gross): |
1000 fpm |
|
Maximum Range: |
425 nm |
|
Empty Weight: |
450 lbs (203.6
kg) |
|
Gross Weight: |
750 lbs (339.4 kg) |
|
Useful Load: |
300 lbs (135.7 kg) |
|
Fuel Capacity: |
11.1 gal (42 l) |
|
Cabin Width: |
21.75 inch (.55 m) |
|
Overall Length: |
15.1 ft (4.6 m) |
|
Height: |
4.8 ft (1.46 m) |
|
Wingspan: |
18.5 ft (5.63 m) |
|
Wing Area: |
68.5 sq ft (6.36 sq m) |
|
Wing Loading: |
10.9 lbs/sq ft (4.9 kg/sq
m) |
|
"G" Loading: |
+4.5g (+6.75g ultimate),
-4.5g |
|
|
|
