Airframe Name |
CAPELLA
XS TD |
|
CAPELLA
XLS TD |
CAPELLA
XLS SUPER 100 TD |
Airframe
Model/'96 and up |
FW2C65TD |
|
FW2C80TD |
FW2C100TD |
Design takeoff
weight |
1100#'s @ FAR
Part 23 Utility Category Load Limits |
Sport Pilot
takeoff weight |
1232#'s @ New
Sport Pilot Category Load Limits |
Maximum
structural takeoff weight |
1270#'s @ FAR
Part 23 Normal Category Load Limits |
Normal takeoff
weight |
925#s |
|
1000#s |
1100#s |
Minimum empty
weight |
480#s |
|
560#s |
575#s |
Wing span |
28.5' |
Wing chord |
4' |
Wing area |
114 Sq. Ft. |
Max wing loading |
9.65# per foot |
Aspect ratio |
7.13:1 |
Power loading |
16.9 #/HP |
|
13.9 #/HP |
11.0#/HP |
Max fuel
capacity |
22 US Gallons
(132#s) |
Aircraft length |
18' 5" |
Aircraft height |
5' 8" |
Cockpit width @
Elbow Level |
43" (With doors
Installed) |
Greater than 45" |
Cockpit width @
Aft Door Sill |
Greater than 37" |
39.5" |
Cockpit width @
Fwd Door Sill |
37" |
39" |
Cockpit height |
40" |
|
Performance |
Airframe Model |
FW2C65TD |
DESIGN SPEEDS |
FW2C80TD |
FW2C100TD |
Performance |
Dual |
Solo* |
calibrated airspeeds @ design takeoff weight |
Dual |
Solo* |
Dual |
Solo* |
Maximum speed at
sea level |
115mph |
116mph |
|
120mph |
121mph |
129mph |
130mph |
True Cruise
Speed, 75% Pwr @ 7K Ft |
110mph |
111mph |
|
119mph |
120mph |
130mph |
131mph |
Stall speed (w/o
flaps) |
46mph |
41mph |
(50mph) |
48mph |
42mph |
50mph |
45mph |
Stall speed
w/flaps |
39mph |
36mph |
(44mph) |
40mph |
38mph |
44mph |
39mph |
Stall speed
w/flaps pwr on |
37mph |
34mph |
|
38mph |
36mph |
39mph |
37mph |
Rate of climb at
sea level |
930fpm |
1200fpm |
|
1180fpm |
1450fpm |
1320fpm |
1600fpm |
Velocity never
exceed |
(140mph) |
Max maneuvering
speed |
96mph |
87mph |
(104mph) |
100mph |
90mph |
104mph |
96mph |
Best angle of
climb |
55-65mph |
Best rate of
climb |
60-80mph |
Takeoff ground
roll (min) |
250ft |
175ft |
|
320ft |
200ft |
275' |
180' |
Landing ground
roll |
175ft |
115ft |
|
200ft |
150ft |
225' |
175' |
Service Ceiling |
10,000’ |
|
14,000’ |
16,000’ |
|
Powerplant |
Airframe Model |
FW2C65TD |
|
FW2C80TD |
FW2C100TD |
Power Plant |
Rotax 582 |
|
Rotax 912 |
Rotax 912S |
Rated output |
66hp |
|
79hp |
100hp |
Displacement
(CC) |
580.7 |
|
1211.2 |
1611.2 |
Type |
2-cycle |
|
4-cycle |
4-cycle |
Propeller
redrive |
2.58:1, 3:1
optional |
|
2.27:1 |
2.45:1 |
Fuel consumption
(75% pwr) |
4.8gph |
|
3.5gph |
4.2gph |
Configuration |
2 cylinder
in-line |
|
4 cylinder
opposed |
4 cylinder
opposed |
Ignition |
dual mag CDI |
|
dual mag CDI |
dual mag CDI |
Lubrication |
oil injection |
|
dry sump oil |
dry sump oil |
