Deperdussin 1913 Racer



Wealthy French silk merchant Armand Deperdussin founded his aircraft-building company Societe Pour les Appareils Deperdussin (SPAD) at Betheny near Reims, in 1910. He was fortunate in employing Louis Bechereau to be responsible for the running of the company and later engaged a young engineering graduate named Andre Herbemont. These two brought undying fame to the original short-lived SPAD organization, which went into liquidation in 1913 after Deperdussin had been arrested for embezzlement.

Bechereau designed a series of monoplanes of increasing capability, perfecting a monocoque form of fuselage construction that combined a desirable circular cross-section with light weight and strength. Typically, the Deperdussins were braced high-wing monoplanes, two king-posts on the forward fuselage carrying a skein of wires to brace the slender wings Lateral control was by wing warping. Landing gear was normally of fixed tailskid type, but sea plane versions had, for their day, a very neat float installation Power was provided for most of the range by Gnome rotary engines of various power outputs.

A first major success came on 9 September 1912, when a Deperdussin powered by a 119-kW (160hp) Gnome and piloted by Jules Vedrines won the fourth James Gordon Bennett Aviation Cup race at Chicago, Illinois. Even greater were the achievements of 1913, Maurice Prevost winning the first Schneider Trophy race at Monaco on 16 April, the Gordon Bennett Cup at Reims, France, on 29 September, and setting a world absolute speed record of 203 85 km/h (126.67 mph) on the same date.

To complete the year's achievements, a Deperdussin piloted by Eugene Gilbert won the Henry Deutsch de la Meurthe air race around Paris on 27 October. Thus, in a few months Bechereau and Herbemont had created for Deperdussin the world's fastest prewar aeroplane from this pinnacle of achievement came collapse of the Deperdussin company. It was taken over by Louis Bleriot and renamed Societe Pour L'Aviation et ses Derives (also SPAD), which gained fame for its products during World War I.

The first plane to break the 200 kph (124 mph) 'barrier', and the first Schneider Trophy winner, was Armand Deperdussin's monoplane. It was the 'speed phenomenon' of the years before the First World War. The plane was developed early in 1912 by Louis Bechereau, the designer for the Societe pour les Appareils Deperdussin. Bechereau worked from an idea by Swedish engineer Ruchonnet, and developed a streamlined monocoque plywood fuselage with a large spinner.

To achieve maximum power two Gnome rotaries were mounted on a common crankshaft. The first noteworthy achievement of this plane was the 1912 Gordon Bennett Cup, which it won with a speed of 108.1 mph (174.01 kph). The plane won the cup again the following year, on September 29,1913 in Reims, Maurice Prevost achieving an average of 124.6 mph (200.5 kph). During this race the plane beat the world speed record three times, and its maximum speed was 126.7 mph (203.85 kph).

A few months earlier, in April 1913, Prevost had won another exceptional victory at the controls of the floatplane version of the Deperdussin monoplane: first place in the first race for the Schneider Trophy in Monaco, with an average speed of 45.75 mph (73.63 kph). The low speed was due to the fact that the judges made Prevost repeat his take-off and about six miles (lOkm) of the course because of a supposed violation of the rules. This Deperdussin victory was the only time in the history of the Schneider Trophy (1912-31) that France won a race.

specifications:

Deperdussin 'Monocoque' racer Manufacturer: Societe pour les Appareils Deperdussin
Year: 1912
Engine: Gnome 14-cylinder air-cooled rotary, 160 hp
Wingspan: 21 ft 9.75 in (6.65 m)
Length: 20 ft (6.1 m)
Height: 7 ft 6.5 in (2.3 m)
Wing area: 104 sq ft (9.66 sq m)
Weight: 1.350 lbs (612 kg)
Speed :130 mph (209 kph)
Frame: ash Covering: plywood, linen

Maximum Endurance: 2 1/2 hrs. (approx)
