MiG-23 Flogger



Origin: USSR
Type: air combat fighter
Max Speed: not disclosed but of a lower standard than that of the MiG-23ML
Max Range not disclosed but of a lower standard than that of the MiG-23ML
Dimensions: span 13.965 m / 45 ft 10 in
length 16.71 m / 54 ft 10 in
height 4.82 m / 15 ft 9.75 in
Weight: not disclosed
Powerplant: one 10000-kg (22,046-lb) afterburning thrust Tumanskii R-27F2M-300 turbojet
Armament: one 23-mm GSh-23L two-barrel cannon with 200 rounds; provision for up to 3000 kg (6,614 Ib) of disposable stores, including AAMs, cannon pods, rocket-launcherpods, large-calibre rockets, and bombs, carried on six external hardpoints
