Nanchang Q-5 Fantan
|
Origin: |
China |
|
Type: |
close-support
fighter with secondary air combat capability |
|
Max Speed: |
642 kt / 739
mph |
|
Max Range |
2,000 km /
1,243 miles |
|
Dimensions: |
span 9.68 m /
31 ft 9 in
length 15.65 m / 51 ft 4.25 in
height 4.33 m / 14 ft 2.75 in |
|
Weight: |
empty 6,375 kg
/ 14,054 lb
max. take-off 11,830 kg /
26,080 lb |
|
Powerplant: |
two 3250-kg
(7,165-lb) afterburning thrust Shenyang WP-6 (Tumanskii R-9BF811)
turbojets |
|
Armament: |
two 23-mm Type
23-2K cannon with 100 rounds per gun; provision for 2000 kg (4,409 Ib)
of disposable stores, including AAMs, free-fall bombs, cluster bombs,
rocket-launcher pods, napalm tanks, drop tanks and ECMS pods, on 10
external hardpoints |
|
|
