SAAB JA 37 Viggen
|
Origin: |
Sweden |
|
Type: |
single-seat
interceptor with secondary attack capability |
|
Max Speed: |
1,146 kt /
1,320 mph |
|
Max Range |
500 km / 311
miles |
|
Dimensions: |
span 10.60 m /
34 ft 9.3 in
length 16.30 m / 53 ft 7.75 in
height 5.90 m / 19 ft 4.3 in |
|
Weight: |
normal
take-off 15,000 kg / 33,060 lb
max. take-off 20,500 kg /
45,194 lb |
|
Powerplant: |
one 12750-kg
(28,109-lb) afterburning thrust Volvo Flygmotor RM8B turbofan |
|
Armament: |
one 30-mm
Oerlikon KCA cannon with 150 rounds; provision for 6000 kg (13,228 Ib)
of disposable stores, including two Rb71 (BAe Sky Flash) and four Rb74
(AIM9L Sidewinder) AAMs or bombs and/or 135-mm (5.31-in)
rocket-launcher pods, carried on six external hardpoints |
|
|
