Sukhoi Su-25 Frogfoot
Origin: |
USSR |
Type: |
single-seat
close-support aircraft |
Max Speed: |
526 kt / 606
mph |
Max Range |
range 750 km /
466 miles |
Dimensions: |
span 14.36 m /
47ft 1.5 in
length 15.53 m / 50ft 11.5 in
height 4.80 m / 15 ft 9 in |
Weight: |
empty 9,500 kg
/ 20,944 lb
max. take-off 17,600 kg /
38,801 lb |
Powerplant: |
two 4500-kg
(9,921-lb) dry thrust Tumanskii R-195 turbojets |
Armament: |
one 30-mm
GSh-30-2 two-barrel cannon with 250 rounds; provision for 4400 kg
(9,700 Ib) of disposable stores, including AAMs, guided bombs, bombs,
cluster bombs, dispenser weapons, napalm tanks, 23-mm cannon pods,
large-calibre rockets, rocket-launcher pods and drop tanks, carried on
eight external hardpoints |
|
|
